Design:

In consideration of the users' operating requirements, we provide a bigger and more stable metal stand with higher quality. The base support provides big space to do the phone repairing and soldering work, as well as great balance while operating. The wheels on both sides make it easy to adjust the working distance and magnification, no matter you are left or right-hander.

For USB output, the white balance, exposure and color adjustment are automatic, they can't be adjusted.

Specification:

Screen Size: 5 inches

Screen Resolution: 480 x 854

Image sensor: 16 Megapixel sony CMOS 1 / 2.9

Pexil size: 2.85 × 2.85μm

Digital zoom: 8 times digital zoom

Video output: Full HD 1080P (via HDMI), 720P (via USB)

Image resolution: 4608 * 3456 (via HDMI)

Video recording: 1080p (via HDMI)

Image format: jpeg

Lens: C / CS

Resolution: 1920 * 1080 @ 30fps, 720p 160 @ fps

TF card interface: max 64G

Pc support: windows XP / 7/8/10 system

Language: English, Chinese, Japanese, French, Germany, Italy, Korean, Turkey, Russia

zoom c-mount lens:

zoom ratio: 5:1

magnification: 0.11X-2X （ about 5x-150x on the 21 inch display )

visual field: 3.1mm-66mm

working distance: 55mm—68000mm

with 35mm ring adapter

camera stand:

Material: Alloy Aluminu

Ring Diameter:35mm(diameter)

solid base plate, high quality, durable and practical

simple design, beauty appearance

 Package including:

1 x Microscope Camera

1 x Power Supply

1 x USB line

1 x HDMI line

1 x Remote Control

1 x 150X Lens

1 x Table Stand
