Model No
HY-5699
Specification
CPU
Max resolution 1080P, high frame frequency, duplex video decoding
4 core Cortex-A17, max frequency 1.8GHz
Support Android 5.1 and above system
Storage interface
Support multiple storage and DDR3L, LPDDR2, LPDDR3
Built-in 2G/8G storage, external SD card is acceptable
Camera video interface
UVC structure, work with external USB camera
Support multiple input format: RAW, RGB and YUV
When using Android tablet, supports 5M CMOS digital imaging, live display by 10-30 frames/sec( resolution 1024*768 and so on).
White balance adjusting and image calibration
Hardware
9.7" retina IPS LCD display, resolution 2048*1536
Support keyboard/mouse input
Five points touch screen
Support max 32G C10 high speed SD card
USB 2.0, HDMI, standard USB2.0 extended interface
Support WIFI access and bluetooth
Sensor
Aptina MT9P001
Scanning
Progressive
Sensor size
1/2.5-inch(4:3)
Effective pixel
2592H*1944V
Effective image size
5.70*4.28mm
7.13mm(diagonal)
Pixel size
2.2um*2.2um
Dynamic range
66.5dB
SNR(max)
40.5dB
A/D exchange resolution
12-bit, on-chip
Sensitivity
0.53V/lux-sec(550nm)
Video format and frames
1600*1200:15fps
Exposure range and format
ERS, auto
